Seraphim Solar Panels
Seraphim specializes in research, development, production, and sales of solar PV products. Since its foundation in 2011, Seraphim has accomplished significant achievements which outpaced most of our main competitors in terms of production capacity and in the number of innovative designs. Seraphim upholds its belief that innovation is the key driver behind advancement by pursuing new technologies and higher efficiencies. Seraphim is accredited as Batch I Smart Manufacturing Plant by Jiangsu Government, the Witness Laboratory Accreditation Certificate (WMTC) by CSA、DEKRA and CTF Laboratory Certificate by TUV SUD.
LIGHT AND ROBUST 16.8 Kgs only
CONVENIENT INSTALLATION
100% EL TEST COMPLETED
THE EXTRA 2% POWER
RELIABLE WARRANTIES
POSITIVE POWER TOLERANCE
| Cells | 6 x 10 |
| Cell vendor | LG |
| Cell type | Monocrystalline |
| Cell dimensions | 156.5 x 156.5 mm / 6 x 6 in |
| # of busbar | 3 |
| Dimensions (L x W x H) | 1640 x 1000 x 35 mm / 64.57 x 39.37 x 1.38 in |
| Static snow load | 5400 Pa / 113 psf |
| Static wind load | 2400 Pa / 50 psf |
| Weight | 16.8 ± 0.5 kg / 36.96 ± 1.1 lb |
| Connector type | MC4 connector IP 67 |
| Junction box | IP 67 with 3 bypass diodes |
| Length of cables | 1000 mm / 39.37 in |
| Glass | High transmission tempered glass |
| Frame | Anodized aluminum |
